| Model |
LT-3000TC |
LT-6000TC |
| power(KW) |
1kw-10kw |
1kw-10kw |
| Maximum Cutting Tube Length |
0-3000mm |
0-6000mm |
| Maximum Tube Diameter |
20-250mm(ouer dia) |
20-250mm(ouer dia) |
| Minimum tailing Length |
100mm (Depends Upon actual cutting) |
100mm (Depends Upon actual cutting) |
| Maximum Accelerated Speed of X/Y Axis |
1 G |
1 G |
| Positioning Accuracy |
±0.05/1000mm |
±0.05/1000mm |
| Repeatability |
±0.03/1000mm |
±0.03/1000mm |
| Maximum Rotational speed |
120rpm |
120rpm |
| Power Requirement |
380V,50/60Hz |
380V,50/60Hz |
| Working Temperature |
5C-45C |
5C-45C |
| Continuous Working Time |
24 Hours |
24 Hours |
| Max Bearing Weight Of Chuck |
200 Kg |
300 Kg |
| Total Installed Capacity |
20-45 KVA |
20-45 KVA |
| Power Supply Protection Level |
IP54 |
IP54 |
| Driven System |
Imported Double Drive |
Imported Double Drive |
